How to setup the Arduino IDE for ESP8266 development

This How To walks you through installing the Arduino IDE and configuring it to program an ESP8266 NodeMCU board. To program the board you can connect a micro USB to USB wire to plug the board into the computer. This guide is part of the Soil Moisture Exporter series.

Prerequisites

• ESP8266 NodeMCU v3
• Micro USB to USB cable

Steps

1. To install it take the latest release from here
2. Add the ESP8266 as a recognised board. Go to File → Preferences then for Additional boards manager URLs add: http://arduino.esp8266.com/stable/package_esp8266com_index.json
3. Install the ESP8266 board via Board manager. Go to Tools → Board → Board Manager, search for ESP8266 and then press Install
4. Select the board by going to Tools → Board → esp8266 → Generic ESP8266 Module
5. Connect your ESP using a USB cable
6. Select the port by going to Tools → Port. The ESP8266 typically appears as COM3 on Windows or /dev/ttyUSB0 on Linux. If you're unsure which port is correct, unplug the board, check which ports are listed, then plug it back in — the new entry is your board.
   • Port not showing up? This is usually a driver issue. The NodeMCU v3 uses a CH340 USB-to-serial chip. Download and install the CH340 driver, then reconnect the board.
   • Still not showing? Try a different USB cable — many micro USB cables are charge-only and won't carry data.
   • On Windows you can verify the port in Device Manager under Ports (COM & LPT). It will appear as USB-SERIAL CH340 (COMx) when the driver is installed correctly.

The board should now appear in Tools → Port as a selectable entry (e.g. COM3 or /dev/ttyUSB0), and the IDE's toolbar will show it as the selected board, e.g. Generic ESP8266 Module on COM3.
